AKC003 vehicles GPS TRACKER

Applications

◆Track Private cars/Vehicle rental /Fleet management/ Equipment outside etc

◆Track container/cargo/credit vehicles, passenger vehicles, taxis, truck, etc…

Support:AIKA APP

Product Features

GPS+LBS+WCDMA+LTE LOCATION

Supports GPS&LBS/WCDMA/LTE.the users are able to use it outside and indoor globally.

VIBRATION ALERT

Build-in sensitive vibration sensor even if a slight vibration for 3second the device will send alarm to owner.

GEO-FENCE

Geo-fence will help you make safe area for your car/families .if carrier is out of safe area the device will send alarm to owner.

WATERPROOF IP65

Super waterproof makes the device can be used in rainy . Never worry about that it is broken when it is rainy.

HISTORICAL ROUTES

The server can store the data for half year so you can check the historical routes in APP&Web platform at any time.

MOVE ALERT

As long as the car is driven far from the sidtace which was set the device will send alarm to the owner via SMS&APP.

OVER SPEED ALERT

Build-in 3G-sensor ,Once the driver is beyong the safe speed that device will send alarm to the user.

BATTERY STANDBY LIFE

Built-in Battery Capacity：180mAH（3.7V Polymer battery –optional)

SOS alarm

Thumb sized button allowing urgent call during an emergency case .

Product specs.

Content	Specs.
Dim.	99mm x 54mm x 16mm
Weight	140g
Network	WCDMA/GSM/GPRS/LET
Band	FDD-LTE：B1/B3/B5/B8 TDD-LTE ：B34/B38/B39/B40/B41;   WCDMA ：B1/B8 TD-SCDMA：B34/B39;   EVDO/CDMA2000 1x：BC0 GSM/EDGE：B3/B8
GPS chip	AT6558D
GPS sensitivity	-162dBm
GPS accuracy	5m
Time To First Fix	Cold status  35-80 s  Warm status  35s Hot status  1s
Work Voltage	DC 9V – 95V

Work Current	12V/45MA
Battery	Rechargeable  3.7V 180mAh Li-ion battery
Standby	90 days
Storage Temp.	-30°C to +80°C
Operation Temp.	-20°C to +70°C
Humidity	5%--95% non-condensing
